1 Introduction The Dell™ Equal Logic™ FS7500 adds scale-out unified Network Attached Storage (NAS) capabilities to Equal Logic PS Series i SCSI SANs so you can easily enable and manage i SCSI, CIFS, a...
Page 6
1.2 Terminology The following terms are used throughout this document. Block I/O Commonly used to describe how an application on a host server accesses data on a local or SAN connected storage system....
Page 7
2 Dell Equal Logic FS7500 The FS7500 is a dual active/active architecture that consists of a redundant pair of appliance-like controller nodes with a backup power supply. The large onboard cache gives...
Page 8
By adding more arrays to the storage pool, the Equal Logic SAN can be scaled out for capacity and performance. NAS volumes and file systems can also be expanded without interruption or downtime. With ...
Page 9
3 Test topology and architecture To study the performance impact of integrating a FS7500 into an existing Equal Logic SAN environment, we needed to generate a workload of both block and file I/O. We c...
Page 10
ports. While this is usually not a recommended best practice for production networks (due to scalability limits), it provided the connectivity we needed for this test environment. On our SAN network, ...
Page 11
4 Test methodology We selected Vdbench for its ability to be controlled by a script and parameter file. For the block I/O testing, we configured Vdbench to read and write from RAW disks without a file...
Page 12
5 Test results and analysis For the combined block and file tests, we observed (see Figure 2) that IOPS increased as additional clients were added. In the three and four array configurations, performa...
Page 13
The caching effect of the FS7500 is also evident when looking at Figure 4, where we see that file I/O clients have a slight performance advantage over the block clients. Furthermore, when we examined ...
Page 14
Figure 4: 6-Array Separated Pool, Block and File I/O Comparison Since additional IOPS capacity was made available to the NAS volumes (doubling the number of physical disk spindles from three to six ar...
Page 15
6 Planning and design considerations 6.1 Network ports Each FS7500 controller contains a total of thirteen 1 Gigabit Ethernet ports that need to be connected for optimal performance. A total of 26 net...
Page 16
• For Adaptive Load Balancing (ALB), four IP addresses are required for each NAS node. For example, in a two-node NAS service, eight NAS service IP addresses are required. • For LACP, one IP address i...
Page 17
workload, then the performance of existing block workloads may be affected as the storage system is forced to share resources between them. 6.4 Volume configuration The FS7500 is able to use the entir...
Page 18
workloads from attached hosts and in some cases may indicate the need for additional disk I/O capacity (i.e., the more physical disk spindles) to satisfy performance needs. Latency is also an importan...
Page 19
7 Summary The Dell Equal Logic FS7500 can be deployed as part of a new installation or into an existing Equal Logic PS Series i SCSI SAN. When deploying into an existing SAN, administrators should mon...
Page 20
Appendix A Vdbench scripts Vdbench script used for block client: Example 1 – Vdbench script used for block client * 100% random 8K, 70% read block I/O test. hd=default sd=default,size=8g,threads=8 sd=...
Page 21
Related publications The following Dell publications are referenced in this document or are recommended sources for additional information. Dell Equal Logic PS Series i SCSI SAN http://www.dell.com/...
Page 22
