Gigabyte Motherboard H410M-H-V3 (rev.1.0) User Manual - English (version 1001)
Summary
The H410M H V3 is a reliable motherboard designed for PC builders and advanced users assembling or upgrading their computer system. This comprehensive user manual serves as your essential guide, covering everything from initial hardware installation—including CPU mounting, memory configuration, and expansion cards—to detailed BIOS setup procedures and driver management. Follow its step-by-step instructions to ensure proper component connectivity and optimize your system settings efficiently.
Page 1 Text Content
User's Manual Rev. 1001
For more product details, please visit GIGABYTE's website.
To reduce the impacts on global warming, the packaging materials of this product are recyclable and reusable. GIGABYTE works with you to protect the environment.
Page Summary Contents For Gigabyte Motherboard H410M-H-V3 (rev.1.0) User Manual - English (version 1001)
Page 1
User's Manual Rev. 1001 For more product details, please visit GIGABYTE's website. To reduce the impacts on global warming, the packaging materials of this product are recyclable and reusable. GIGABYT...
Page 2
Copyright © 2021 GIGA-BYTE TECHNOLOGY CO., LTD. All rights reserved. The trademarks mentioned in this manual are legally registered to their respective owners. Disclaimer Information in this manual is...
Page 3
Table of Contents H410M H V3 Motherboard Layout ...................................................................................4 Chapter 1 Hardware Installation ......................................
Page 4
H410M H V3 Motherboard Layout KB_MS ATX_12V_2X4 CPU_FAN SYS_FAN LGA1200 SATA3 USB20 M2 A_ SB DD R4 _A USB_LAN DD R4 _B AUDIO PCIEX16 Gb E LAN Chip i TE® Super I/O Intel® H510 PCIEX1_1 CODEC M_BIOS CLR...
Page 5
Chapter 1 Hardware Installation 1-1 Installation Precautions The motherboard contains numerous delicate electronic circuits and components which can become damaged as a result of electrostatic dischar...
Page 6
1-2 Product Specifications CPU Support for 10th Generation Intel® Core™ i9 processors/Intel® Core™ i7 processors/ Intel® Core™ i5 processors/Intel® Core™ i3 processors/Intel® Pentium® processors/ Inte...
Page 7
USB Chipset: - 4 x USB 3.2 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header) - 6 x USB 2.0/1.1 ports (4 ports on the back panel, 2 ports available through the ...
Page 8
Unique Features Support for APP Center * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specificatio...
Page 9
1-3 Installing the CPU Read the following guidelines before you begin to install the CPU: Make sure that the motherboard supports the CPU. (Go to GIGABYTE's website for the latest CPU support list.) A...
Page 10
The two DDR4 memory sockets are divided into two channels and each channel has one memory socket as following: Channel A: DDR4_A1 Channel B: DDR4_B1 Due to CPU limitations, read the following guidelin...
Page 11
RJ-45 LAN Port The Gigabit Ethernet LAN port provides Internet connection at up to 1 Gbps data rate. The following describes the states of the LAN port LEDs. Connection/ Speed LED Activity LED Activit...
Page 12
1-7 Internal Connectors 1) ATX_12V_2X4 9) F_AUDIO 2) ATX 10) F_U32 3) CPU_FAN 11) F_USB 4) SYS_FAN 12) COMA 5) LED_C 13) SPI_TPM 6) SATA3 0/1/2/3 14) CLR_CMOS 7) M2A_SB 15) BAT 8) F_PANEL Read the fol...
Page 13
DEBUG PORT DE BU PO RT DEBUG PORT 1/2) ATX_12V_2X4/ATX (2x4 12V Power Connector and 2x12 Main Power Connector) With the use of the power connector, the power supply can supply enough stable power to a...
Page 14
DE BU DE BU PO RT PO RT DE BU DE BU PO RT PO RT DEBUG PORT 5) LED_C (RGB LED Strip Header) The header can be used to connect a standard 5050 RGB LED strip (12V/G/R/B), with maximum power rating of 2A ...
Page 15
F_USB30 F_ U F_ F_ F_USB3 F 7) M2A_SB (M.2 Socket 3 Connector) The M.2 connector only supports M.2 PCIe SSDs. HD ED HD PL ED RE S- PW RE S+ PW B_ CI SP EA K+ PW R_ LE D+ NC Follow the steps below to ...
Page 16
9) F_AUDIO (Front Panel Audio Header) The front panel audio header supports High Definition audio (HD). You may connect your chassis front panel audio module to this header. Make sure the wire assignm...
Page 17
F_USB30 F_ U F_ F_ 12) COMA (Serial Port Header) _ S The COM header can provide one serial port via an optional COM port cable. For purchasing the optional S_ COM port cable, please contact the loca...
Page 18
15) BAT (Battery) The battery provides power to keep the values (such as BIOS configurations, date, and time information) in the CMOS when the computer is turned off. Replace the battery when the batt...
Page 19
Chapter 2 BIOS Setup BIOS (Basic Input and Output System) records hardware parameters of the system in the CMOS on the motherboard. Its major functions include conducting the Power-On Self-Test (POST)...
Page 20
2-2 The Main Menu System Setup Menus Configuration Items Hardware Information Option Description Current Settings Quick Access Bar allows you to quickly move to the General Help, Easy Mode, Smart Fan ...
Page 21
2-3 Favorites (F11) Set your frequently used options as your favorites and use the <F11> key to quickly switch to the page where all of your favorite options are located. To add or remove a favo...
Page 22
2-4 Tweaker Whether the system will work stably with the overclock/overvoltage settings you made is dependent on your overall system configurations. Incorrectly doing overclock/overvoltage may result ...
Page 23
Intel(R) Speed Shift Technology (Intel® Speed Shift Technology) (Note) Enables or disables Intel® Speed Shift Technology. Enabling this feature allows the processor to ramp up its operating frequency ...
Page 24
C-States Control CPU Enhanced Halt (C1E) Enables or disables Intel® CPU Enhanced Halt (C1E) function, a CPU power-saving function in system halt state. When enabled, the CPU core frequency and voltage...
Page 25
Core Current Limit (Amps) Allows you to set a current limit for CPU Turbo mode. When the CPU current exceeds the specified current limit, the CPU will automatically reduce the core frequency in order ...
Page 26
Realtime Memory Timing Allows you to fine-tune memory timings after the BIOS stage. (Default: Auto) Memory Enhancement Settings Provides several memory performance enhancement settings: Auto, Relax OC...
Page 27
2-5 Settings Platform Power Platform Power Management Enables or disables the Active State Power Management function (ASPM). (Default: Disabled) PEG ASPM Allows you to configure the ASPM mode for the ...
Page 28
Er P Determines whether to let the system consume least power in S5 (shutdown) state. (Default: Disabled) Note: When this item is set to Enabled, the following functions will become unavailable: Resum...
Page 29
Audio Controller Enables or disables the onboard audio function. (Default: Enabled) If you wish to install a 3rd party add-in audio card instead of using the onboard audio, set this item to Disabled. ...
Page 30
Media detect count Allows you to set the number of times to check the presence of media. This item is configurable only when Network Stack is enabled. (Default: 1) NVMe Configuration Displays informat...
Page 31
PC Health Status Reset Case Open Status Disabled Keeps or clears the record of previous chassis intrusion status. (Default) Enabled Clears the record of previous chassis intrusion status and the Case ...
Page 32
2-6 System Info. This section provides information on your motherboard model and BIOS version. You can also select the default language used by the BIOS and manually set the system time. Access Level ...
Page 33
2-7 Boot Bootup Num Lock State Enables or disables Numlock feature on the numeric keypad of the keyboard after the POST. (Default: On) Security Option Specifies whether a password is required every ti...
Page 34
USB Support Disable Link All USB devices are disabled before the OS boot process completes. Full Initial All USB devices are functional in the operating system and during the POST. (Default) Partial I...
Page 35
Administrator Password Allows you to configure an administrator password. Press <Enter> on this item, type the password, and then press <Enter>. You will be requested to confirm the passwo...
Page 36
2-8 Save & Exit Save & Exit Setup Press <Enter> on this item and select Yes. This saves the changes to the CMOS and exits the BIOS Setup program. Select No or press <Esc> to return...
Page 37
Chapter 3 Appendix Drivers Installation Before installing the drivers, first install the operating system. After installing the operating system, insert the motherboard driver disc into your optical d...
Page 38
Regulatory Notices United States of America, Federal Communications Commission Statement Supplier's Declaration of Conformity 47 CFR § 2.1077 Compliance Information Product Name: Motherboard Trade Nam...
Page 39
Contact Us GIGA-BYTE TECHNOLOGY CO., LTD. Address: No.6, Baoqiang Rd., Xindian Dist., New Taipei City 231, Taiwan TEL: +886-2-8912-4000, FAX: +886-2-8912-4005 Tech. and Non-Tech. Support (Sales/Market...
