Dell P2213 Monitor Outline Drawing User's Manual
Summary
This document contains technical specifications and dimensional drawings for a Dell monitor. It provides measurements including swivel angles (45 degrees), pivot capabilities (90 degrees), tilt angles (4 to 21 degrees), and physical dimensions in millimeters. Target users are system integrators and workspace planners needing precise monitor dimensions for installation or mounting configurations.
Manual Details
| Brand | Dell |
|---|---|
| Pages | 3 |
| File Size | 4.43 MB |
| Published | June 29, 2026 |
Enter the captcha to get the download link:
Frequently Asked Questions
What is the maximum angle of monitor swivel adjustment?
The device supports a fixed 45-degree swivel range.
Does the unit support vertical or side adjustments beyond the main swivel?
Yes, it includes pivoting up to 90 degrees and tilting capabilities based on dimensional measurements provided.
What are the physical dimensions of this monitor setup?
The overall width is listed at 552.9 units, with a depth measurement of approximately 14.0 units.
Is the unit designed for wall mounting or does it require its stand?
Specifications reference a 'Monitor without stand,' suggesting it is meant to be mounted or integrated separately.
