AD9241 Analog Devices Data Handbook/Manual
Summary
This high-performance AD9241 is a 14-bit, 1.25 MSPS monolithic ADC designed for demanding applications. It offers superior signal integrity with single supply power, ultra-low power dissipation, and robust digital error correction logic. The manual provides comprehensive technical specifications detailing flexible data input/output options, excellent DC and AC performance metrics, making it ideal for engineers developing imaging, communications, medical, and advanced data acquisition systems.
Manual Details
| Brand | Analog Devices |
|---|---|
| Pages | 24 |
| File Size | 375.37 KB |
| Published | June 15, 2026 |
Enter the captcha to get the download link:
Frequently Asked Questions
What is the required power supply for the AD9241?
It operates on a single +5 V supply and consumes only 60 mW.
Does the ADC support various input types?
Yes, it supports both single-ended and differential inputs of varying input spans.
What guarantees prevent missing codes?
The device uses digital output error correction logic to guarantee no missing codes over the full operating temperature range.
