LCD MONITOR quick start guide
700DXn, 820DXn
Page Summary Contents For Samsung 820DXN LCD Monitor Quick User Guide
Page 1
LCD MONITOR quick start guide 700DXn, 820DXn
Page 2
Select Language Main Page Model Safety Instructions Introduction Package Contents Your LCD Display Mechanical Layout Connections The color and appearance of the product may vary depending on the model...
Page 3
Batteries (AAA X 2) BNC to RCA Remote Control (Not available in all Adaptor Jack locations) Sold separately Wall Mount KIT DVI Cable BNC Cable LAN Cable Your LCD Display 1) MENU Opens the on-screen me...
Page 4
PC AV / S-Video / Component / HDMI Mode BNC AV / S-Video / HDMI Mode DVI AV / S-Video / Component Mode AV / S-Video PC / BNC / DVI Mode Component PC / DVI Mode HDMI PC / BNC Mode 7) Power button Turns...
Page 5
2) REMOTE OUT/IN You can use a wired remote control by connecting it to your monitor. 3) RS232C OUT/IN (RS232C Serial PORT) MDC(Multiple Display Control) Program Port 4) DVI / PC / HDMI IN [HDMI/PC/DV...
Page 6
The number of LCD Displays that can be connected to loopout may differ depending on the cables, signal source etc. With cables where there is no degradation or signal source, up to ten LCD Displays ca...
Page 7
3) MDC MDC Quick Launch Button. 4) LOCK Activates or deactivates all function keys on both the remote control and the LCD Display except for the Power and LOCK buttons. 5) Magic Net buttons Used for M...
Page 8
When pressing this button, the current mode is displayed at the bottom centre of the screen. The LCD Display has a built-in high fidelity stereo amplifier. Then press the button again to circle throug...
Page 9
Select Language Main Page Model Safety Instructions Introduction Connections Installing the Stand KIT Connecting the LCD Display The color and appearance of the product may vary depending on the model...
Page 10
Using a Power cord with Earth In the event of failure, the earth lead may cause electric shock. Make sure to wire the earth lead in correctly, before connecting the AC power. When un-wiring the earth ...
Page 11
3) Connect the audio cable for your LCD Display to the audio port on the back of your computer. Turn on both your computer and the LCD Display. The DVI cable or BNC cable is optional. Contact a local ...
Page 12
1) Connect a set of audio cables between the COMPONENT AUDIO IN [L-AUDIO-R] on the LCD Display and the AUDIO OUT jacks on the DVD player. 2) Connect a Component cable between the BNC/COMPONENT IN - PR...
Page 13
The audio-video cables shown here are usually included with a Camcorder. (If not, check your local electronics store.) If your camcorder is stereo, you need to connect a set of two cables. Connecting ...
Page 14
Connect a set of audio cables between the AUX L, R jacks on the AUDIO SYSTEM and the AUDIO OUT [L-AUDIO-R] on LCD Display. Connecting to a Wired Remote Control You can control your monitor by allowing...
Page 15
1) Connect the DVI output terminal of a digital output device to the HDMI IN terminal of the monitor using a DVI to HDMI cable. 2) Connect the red and white jacks of an RCA to stereo (for PC) cable to...
Page 16
Select Language Main Page Model Safety Instructions Introduction Connections Using the Software Adjusting the LCD Display Troubleshooting The color and appearance of the product may vary depending on ...
Page 17
Maintenance and Cleaning 1) Maintaining the LCD Display Case. Clean with a soft cloth after disconnecting the power cord. Do not use benzene, thinner or other flammable substances, or a wet cloth. We ...
Page 18
The LCD Display screen flickers. Display is securely connected. (Refer to Connecting a Computer) Problems related to the Screen Problems related to the LCD Display screen and their solutions are liste...
Page 19
Problems related to audio signals and their solutions are listed below. Problems Solutions No sound. Ensure that the audio cable is firmly connected to both the audio-in port on your LCD Display and t...
Page 20
Set the resolution in the Control Panel → Appearance and Themes → Display → Settings. Windows ME/2000: Set the resolution in the Control Panel → Display → Settings. * Contact the video card manufactur...
