Philips 74ABT16501A, 74ABTH16501A Data Manual
Summary
This high-performance 18-bit universal bus transceiver is designed for reliable, bidirectional data transfer interfaces requiring low static/dynamic power consumption. It features integrated 3-State outputs and incorporates flexible control logic, including dedicated enable signals and clocking inputs, allowing operation in clocked, transparent, or latched modes. Ideal for electronics designers, the manual provides comprehensive technical specifications, pin configurations, detailed operational parameters, and model variations (with and without bus-hold capability) required to implement robust data bus connectivity solutions.
Page 1 Text Content
INTEGRATED CIRCUITS查询74ABT16501A供应商
74ABT16501A 74ABTH16501A 18-bit universal bus transceiver (3-State)
Product specification 1998 Feb 27 Supersedes data of 1997 Jun 12 IC23 Data Handbook
Page Summary Contents For Philips 74ABT16501A, 74ABTH16501A Data Manual
Manual Details
| Brand | Philips |
|---|---|
| Pages | 13 |
| File Size | 91.85 KB |
| Published | June 18, 2026 |
Enter the captcha to get the download link:
Frequently Asked Questions
What is the difference between 74ABT16501A and 74ABTH16501A?
74ABT16501A lacks bus-hold, while 74ABTH16501A incorporates bus-hold on data inputs.
What is the typical propagation delay for this transceiver?
Typical propagation delay (An to Bn or Bn to An) is 2.2 ns (tPLH) or 1.8 ns (tPHL) at Vcc=5V, 25°C.
Which package options are available for the 74ABTH16501A?
Available in 56-pin SSOP Type III (SOT371-1) or TSSOP Type II (SOT364-1), ranging from -40°C to +85°C.
How many VCC and GND pins does this IC have?
It has 4 VCC pins (pins 7, 22, 35, 50) and 9 GND pins (4, 11, 18, 25, 32, 39, 46, 53, 29).
What handling precautions are stated for moisture sensitivity?
This component is moisture sensitive (MSL 3); follow IPC/JEDEC J-STD-020 handling requirements after exposure to moisture.
