Page 2
En gl is English Congratulations on your purchase of the GIGABYTE Notebook. This manual will help you to get started with setting up your notebook. The final product configuration depends on the model...
Page 3
English En gl is Booting Up the Notebook for the First Time Depending on your configuration, the Microsoft® Windows® Boot Screen will be the first screen that you will see as the notebook starts up. F...
Page 4
En gl is English Left View Kensington Lock Slot Ethernet Port USB 3.0 Port SD Card Reader Headphone Jack Microphone Jack Right View Mini Display Port USB 3.0 Port (USB Charge) USB 3.1 Port HDMI Port E...
Page 5
English En gl is Hotkeys The computer employs hotkeys or key combinations to access most of the computer’s controls like screen brightness and volume output. To activate hotkeys, press and hold the &l...
Page 6
En gl is English Swappable bay Application Unlock swappable bay locker. Draw the swappable bay out. 9.5mm HDD/SSD only Connect the HDD or SSD pin by sliding it into the connecter.
Page 7
English En gl is Gently push the plastic frame outwards. Slide in the HDD or SSD until it locks into place. There will be a slight click. Pull swappable bay back to slot. Lock swappable bay locker.
Page 8
En gl is English Macro Hub Instruction Welcome to use Macro Hub ! Macro Hub makes it much easier for you to control your Macro Key on P37. You can deal with complex key stroke combination by just one ...
Page 9
English En gl is Using Macro Hub Set Macro Key to basic function a. Click the G button on the left-top of the b. Click the Macro Key function brick keyboard to switch to the Macro Key group you would ...
Page 10
En gl is English Edit macro command funtions anf settings. a. Click "Macros" (you can set up to 100 sets of macro) b. Overview of macro record panel (you can record your own macro here) 1. S...
Page 11
English En gl is 11. Delete selected: Delete selected movement 12. Movement list: it shows all movement you record 13. Exit: The system will inquire you if to save the recorded macro c. Start to recor...
Page 12
En gl is English Edit "Settings" of Macro Hub 1. Software update: Update latest version of GIGABYTE Macro Hub 2. Clean memory: Erase current Macro Hub settings 3. Firmware Upgrade: Upgrade M...
Page 13
English En gl is GIGABYTE Software Application GIGABYTE Smart Manager You can activate GIGABYTE Smart Manager by double clicking on the shortcut icon on the desktop if the machine you purchased has th...
Page 14
En gl is English Smart USB Backup Guide WARNING You can backup original recovery image through this application in case of losing by device damage. You can backup original recovery image to USB disk a...
Page 15
English En gl is Recovery Guide System Recovery (Restore your laptop operating system) When something is going wrong with the laptop operating system, the storage of the laptop has a hidden partition ...
Page 16
En gl is English A progress indicator bar will show on the window when the recovery process is running. Please make sure the AC-adapter is plugged in and do not turn off the laptop. Reboot the laptop ...
Page 17
English En gl is ▓▓ ▓Choose “Reset this PC” Keep my files Choose an account to continue.All apps will be removed, and settings will back to pure O/S (without GIGABYTE app), but your personal files w...
Page 18
En gl is English Advanced options System Restore Use a restore point recorded on your PC to restore Windows. System Image Recovery Recover Windows using a specific system image file. Startup Repair Fi...
Page 19
English En gl is Appendix Warranty & Service: Warranty and service and related information please refer to the warranty card or GIGABYTE service website as the below link: http://www.gigabyte.com/...
