Operation and Maintenance Manual
126858E Rev. F November 2014
Bettis M11 Hydraulic Override System For HD, T, and G-Series Pneumatic and Hydraulic Actuators
Page Summary Contents For EMERSON Manuals Bettis M11 Hydraulic Override System for HD, T, and G-Series Pneumatic and Hydraulic Actuators
Page 1
Operation and Maintenance Manual 126858E Rev. F November 2014 Bettis M11 Hydraulic Override System For HD, T, and G-Series Pneumatic and Hydraulic Actuators
Page 3
Operation and Maintenance Manual Table of Contents 126858E Rev. F November 2014 Table of Contents Section 1: Introduction 1.1 General M11 Service Information .............................................
Page 4
Section 1: Introduction Operation and Maintenance Manual November 2014 126858E Rev. F Section 1: Introduction 1.1 General M11 Service Information 1.1.1 M11 is a compact modular hydraulic override syst...
Page 5
Operation and Maintenance Manual Section 1: Introduction 126858E Rev. F November 2014 CAUTION: APPLY THREAD SEALANT Apply thread sealant per the manufacturer's instructions. 1.2 Definitions WARNING If...
Page 6
Section 1: Introduction Operation and Maintenance Manual November 2014 126858E Rev. F 1.4 Fluid Requirements 1.4.1 M11 Manual Hydraulic Override System Fluid Requirements: Hydraulic fluids, other than...
Page 7
Operation and Maintenance Manual Section 2: General Information 126858E Rev. F November 2014 Section 2: General Information 2.1 Actuator Power Operation CAUTION: PLACE CONTROL KNOB IN AUTO POSITION Po...
Page 8
Section 3: M11 System Fluid Filling Instructions Operation and Maintenance Manual November 2014 126858E Rev. F Section 3: M11 System Fluid Filling Instructions 3.1 Double-Acting Actuator M11 System Fl...
Page 9
Operation and Maintenance Manual Section 3: M11 System Fluid Filling Instructions 126858E Rev. F November 2014 3.1.2.2.3 HD-Series Actuators, remove pipe plug from the top area on the outer end of the...
Page 10
Section 3: M11 System Fluid Filling Instructions Operation and Maintenance Manual November 2014 126858E Rev. F NOTE: Add fluid to the reservoir through the open port left vacant in Step 3.1.2.10. 3.1....
Page 11
Operation and Maintenance Manual Section 3: M11 System Fluid Filling Instructions 126858E Rev. F November 2014 3.1.3.6 Stop pumping the M11 pump handle when hydraulic fluid appears at both vacant pipe...
Page 12
Section 3: M11 System Fluid Filling Instructions Operation and Maintenance Manual November 2014 126858E Rev. F NOTE: The pressure pump should not exceed 10 to 20 psi when force filling the M11 hydraul...
Page 13
Operation and Maintenance Manual Section 3: M11 System Fluid Filling Instructions 126858E Rev. F November 2014 NOTE: Only remove the pipe plugs located at the highest points, in the vertical plane, of...
Page 14
Section 4: M11 Disassembly Instructions Operation and Maintenance Manual November 2014 126858E Rev. F Section 4: M11 Disassembly Instructions 4.1 M11 Pressure Release Instructions NOTE: Shut off and e...
Page 15
Operation and Maintenance Manual Section 4: M11 Disassembly Instructions 126858E Rev. F November 2014 4.2.2 Loosen socket cap screws (30-20) and remove the M11 reservoir from the M11 mounting bracket ...
Page 16
Section 4: M11 Disassembly Instructions Operation and Maintenance Manual November 2014 126858E Rev. F 4.3.4 Refer to Assembly Drawing. To remove the check valve (20-40) from the manifold (20-10), move...
Page 17
Operation and Maintenance Manual Section 4: M11 Disassembly Instructions 126858E Rev. F November 2014 4.3.15 Remove pivot pin (20-130) from pump rod (20-50). NOTE: If the M11 pump is equipped with Aut...
Page 18
Section 5: M11 Reassembly Instructions Operation and Maintenance Manual November 2014 126858E Rev. F Section 5: M11 Reassembly Instructions 5.1 M11 General Reassembly Instructions CAUTION: INSTALL NEW...
Page 19
Operation and Maintenance Manual Section 5: M11 Reassembly Instructions 126858E Rev. F November 2014 5.2.1 Refer to the Assembly Drawing. If disassembled, reassemble the following items: 5.2.1.1 Pipe ...
Page 20
Section 5: M11 Reassembly Instructions Operation and Maintenance Manual November 2014 126858E Rev. F 5.3.2 Install one check valve (20-40) with O-ring seal into the bottom of pump rod (20-50). 5.3.3 I...
Page 21
Operation and Maintenance Manual Section 5: M11 Reassembly Instructions 126858E Rev. F November 2014 5.3.16 If removed, install two pump links (20-60). Retain the two pump link to pump cover (20-20) u...
Page 22
Section 5: M11 Reassembly Instructions Operation and Maintenance Manual November 2014 126858E Rev. F 5.3.28 Install the control knob (20-320) onto the control valve (20-190). 5.3.29 Retain the control...
Page 23
Operation and Maintenance Manual Section 6: Modifications 126858E Rev. F November 2014 Section 6: Modifications 6.1 M11 Pump Handle Reorientation 6.1.1 Remove the four socket cap screws (20-110) from ...
Page 24
Section 7: Document Revision Operation and Maintenance Manual November 2014 126858E Rev. F Section 7: Document Revision Table 1. Revision Overview ECN DATE REV BY * DATE 26 October 06 COMPILED L. Rami...
Page 25
Operation and Maintenance Manual Section 8: Appendix 126858E Rev. F November 2014 Appendix A: List of Drawings A.1 Part No. VA127247-Q, M11 Assembly Drawing Appendix
Page 26
Section 8: Appendix Operation and Maintenance Manual November 2014 126858E Rev. F A.2 Part No. VA135978-A, M11 Installation Drawing Appendix
Page 28
