Power Edge Product Group Development

Power Edge R740 Family of Servers

Servers, optimized Designing servers optimized for purpose and workload is part of the Power Edge

Tech Note by:

design process. A highly-adaptable server like the Power Edge R740 provides Tad Walsh extensive configuration flexibility, allowing it to be tailored to the specific demands of a wide range of workloads. Yet even more differentiated designs in the same 2-socket space are needed to meet the emerging demands of highly data-intensive workloads. Thus we see additional servers (the Power Edge R740xd and R740xd2) in the same general space, in order to provide peak

SUMMARY

capabilities for those data-abundant use cases.

The Power Edge R740 rack server family is comprised of

Power Edge R740

three members: R740, R740xd,

The Power Edge R740 is a 2u rack server providing a balanced architectural

and R740xd2.

design for driving peak 2-socket performance and cost-efficient operation. It supports up to two processors from the broad range of offerings in the Intel

This tech note compares and

Xeon Scalable Processor family; 24 DIMM slots for RDIMMs/LRDIMMs or

contrasts these three servers,

alternatively for up to 12 NVDIMMs; and up to eight PCIe Gen 3 I/O slots (one

giving an overview of their

of which will be taken by the PERC adapter). Large, front-accessible storage

technical specifications and

capacity is provided by up to 16 x 2.5” SAS or SATA (HDD/SSD) drives, or up

capabilities, and calling out key

to 8 x 3.5” SAS or SATA HDD. Furthermore, the innovative Power Edge Boot

workloads for which they are

Optimized Storage Subsystem (BOSS) in the R740 offers up to two M.2 SSD’s

optimized.

for the segregation of operating system from data.

The R740 offers broad configuration flexibility, allowing it to be tailored for the requirements of a wide range of workloads and applications including OLTP, Decision Support, Xaa S, web tech, server virtualization, desktop virtualization (VDI), and HPC. For users needing to drive application performance beyond the 2-socket range, the R740 also supports numerous GPU and FPGA options, enabling users to stay at the forefront of emerging application areas such as ML/DL, AI, and business-oriented HPC.

In the realm of high availability features, the R740 offers multiple hot-plug power supplies for full redundancy, and these power supplies can be chosen from a range of wattages, allowing users to choose the appropriate type of power supply based on the needs of their workloads and server configuration. Cooling comes from up to six fully-redundant hot-plug fans.

Image 1: Power Edge R740 (left) and Power Edge R740xd (right). Yes, they look the same from the outside.
