Dell EMC VEP4600 Installation Guide March 2022
March 2022 Rev. A08
Page Summary Contents For Dell EMC VEP4600 Installation Guide - March 2022
Page 1
Dell EMC VEP4600 Installation Guide March 2022 March 2022 Rev. A08
Page 2
Notes, cautions, and warnings NOTE: A NOTE indicates important information that helps you make better use of your product. CAUTION: A CAUTION indicates either potential damage to hardware or loss of d...
Page 3
Contents Chapter 1: About this guide........................................................................................................... Related documents..........................................
Page 4
Fan module installation.....................................................................................................................................................29 Fan module replacement......
Page 5
About this guide This guide provides site preparation recommendations, step-by-step procedures for rack mounting and desk mounting your platform, inserting modules, and connecting to a power source. C...
Page 6
Information symbols This book uses the following information symbols: NOTE: The Note icon signals important operational information. CAUTION: The Caution icon signals information about situations that...
Page 7
VEP4600 platform The following sections describe the Dell EMC Virtual Edge Platform 4600 (VEP4600) platform: Topics: Introduction Features Physical dimensions LED display Pre-requisites VEP4600 config...
Page 8
Figure 3. VEP4600 PSU-side 1. PSUs 2. Fans Features The VEP4600 platform offers the following features: Two 10Gb E SFP+ ports Four 1000Base-T ports One Micro USB type-B console port Two USB Type-A por...
Page 9
LED behaviors Figure 4. VEP4600 LEDs 1. Power LED 2. Primary unit indicator LED 3. System LED 4. Locator LED 5. Temperature LED 6. Fan LED 7. SFP+ indicator LED 8. 10/100/1000 Base T RJ-45 networking ...
Page 10
Table 1. VEP4600 LED behavior (continued) LED Description Flashing yellow—PSU warning event; power continues to operate LOCATOR LED/System Beacon Off—Locator function disabled Flashing blue with 1 sec...
Page 11
Figure 5. r NDC front panel LED call-outs Table 4. Expansion card LEDs LED Description 1.) System LED Off—Card is off Solid green—Normal operation Solid yellow—Citical card error Flashing green—Bootin...
Page 12
VEP4600 configurations You can order the VEP4600 in the following configuration: Two 10Gb E SFP+ and four 1000 Base-T ports, one or two AC PSU power supplies, and four or five normal fan subsystems wi...
Page 13
Site preparations VEP4600 is universal customer premise equipment (u CPE). To connect the service provider edge or enterprise branch to the cloud, use VEP4600 to host multiple virtual network function...
Page 14
The cabinet must meet minimum size requirements. Airflow must be in accordance with the Electronic Industries Alliance (EIA) standard. Ensure that there is a minimum of 5 inches (12.7 cm) between the ...
Page 15
Short push: Sends ACPI power event to the Operating System (OS.) NOTE: Response depends on configuration of how the OS is booted-up when it receives a ACPI power event. The response may ignore the but...
Page 16
VEP4600 installation To install the VEP4600, complete the installation procedures in the order presented in this section. Always handle the platform and components with care. Avoid dropping the platfo...
Page 17
CAUTION: Professional installation instructions: This product is designed for specific applications and needs to be installed by qualified personnel with RF and regulatory related knowledge. The gener...
Page 18
Rack or cabinet hardware installation You may either place the platform on a rack shelf or mount the platform directly into a 19" wide, EIA-310- E-compliant rack. The platform includes two-post r...
Page 19
Figure 9. Reverse small bracket Figure 10. Reversed rail mounting bracket position 3. Mount unit on front-mount (flush-mount) rails. Figure 11. Platform flush-mounted on two posts Two-post installatio...
Page 20
Figure 12. Two-post rail Four-post installation To complete this installation, supply eight rack-mounting screws. NOTE: For more installation instructions, see the installation labels attached to the ...
Page 21
Figure 14. Platform four-post front installed 5. Align the rear rack rails to the front rail and slide into place. Figure 15. Rear platform rail About three inches before you fully insert your platfor...
Page 22
WARNING: When working with optical fibers, follow all warning labels and always wear eye protection. Never look directly into the end of a terminated or unterminated fiber or connector as it may cause...
Page 23
Power supplies VEP4600 power supply specifications, installation, and replacement. The VEP4600 ships with one or two AC power supplies, depending on the configuration. Airflow is from the front to bac...
Page 24
DC PSU LEDs 1. DC PSUs Solid green—Input voltage ok and output good. Flashing yellow (amber)—There is a Standby mode or PSU failure (OC, OT, OV, Fan fault). Off—PSU is off. AC power supply installatio...
Page 25
AC power supply replacement CAUTION: Disconnect the power cord before removing the power supplies. Also, disconnect all power cords before servicing. NOTE: The PSU slides into the slot smoothly. Do no...
Page 26
Figure 18. Molex terminal block 7. Tighten the screws with a number 1 Philips screwdriver on the terminal block to secure the number 10 to number 3 AWG wires. Figure 19. Tighten wires to terminal bloc...
Page 27
Figure 20. Mate terminal block to DC PSU 9. Locate the overlay label in the kit and place it over the existing label in the unit. Figure 21. DC overlay label 10. Insert DC PSUs to switch. Figure 22. I...
Page 28
Figure 23. Ground lug 12. Attach ground wire to switch. Secure ground lug with a number 1 Philips screwdriver. Figure 24. Attach ground lug and wire to switch NOTE: Torque screws to 6-inch pounds. Fig...
Page 29
The VEP4600 comes from the factory with one or two PSUs and four or five fan modules installed in the platform, depending on the configuration. The fan modules and the power supplies, which have integ...
Page 30
1. Fan module installation Fan module replacement To request a hardware replacement, see www.dell.com/support. CAUTION: Complete the following steps within one minute or the platform temperature could...
Page 31
Management ports Besides the 10/100/1000Base-T RJ-45 ports, the VEP4600 provides several ports for management and storage. NOTE: The output examples in this section are for reference only. Your output...
Page 32
Micro USB-B console port access The Micro USB-B console port is on the front below the two USB ports on the VEP4600. The terminal settings are the same for the serial console port and the RS-232/RJ-45...
Page 33
Specifications This section lists the VEP4600 specifications. CAUTION: Operate the product at an ambient temperature not higher than 113°F (45°C). NOTE: For Ro HS information, see Restricted Material ...
Page 34
Table 8. AC power requirements Parameter Specifications AC power supply 100–240 VAC 50/60 Hz Typical current draw per platform 110VAC: 1.89A (16 core) 240VAC: 0.86 A (16 core) 110VAC: 1.5A (8 core ) 2...
Page 35
Waste electrical and electronic equipment (WEEE) directive for recovery, recycle and reuse of IT and telecommunications products Dell EMC platforms are labeled in accordance with European Directive 20...
Page 36
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set ...
Page 37
India This product conforms to the relevant Essential Requirements of TEC, Department of Telecommunications, Ministry of Communications, Govt of India, New Delhi-110001. Japan VCCI compliance for clas...
Page 38
Figure 32. Korean package label Mexico certification of compliance La operación de este equipo está sujeta a las siguientes dos condiciones: 1. Es posible que este equipo o dispositivo no cause interf...
Page 39
Thailand radio compliance certificate Thailand radio compliance certificate translated Singapore certification of compliance Singapore radio compliance. Complies with IMDA Standards Registration numbe...
Page 40
Dell EMC support The Dell EMC support site provides documents and tools to help you use Dell EMC equipment and mitigate network outages. Through the support site you can obtain technical information, ...
