This user manual provides comprehensive operational and setup instructions for the TFT-LCD SMT-1721/SMT-1921 series monitors. Designed as a reliable display solution with multiple inputs (VGA, BNC, Audio), these 17” and 19” monitors are ideal for professional applications needing stable performance. The guide covers product specifications, detailed safe setup procedures, advanced menu operation, and crucial safety warnings to ensure authorized users can operate the monitor correctly and safely in various environments.
Page 1 Text Content
TFT-LCD MONITOR SMT-1721 / SMT-1921
User Guide
Page Summary Contents For Samsung Soundbar SMT-1721 User Guide - Part 2: Product
Page 1
TFT-LCD MONITOR SMT-1721 / SMT-1921 User Guide
Page 2
TFT-LCD MONITOR SMT-1721 / SMT-1921
Page 3
USER'S MANUAL IMPORTANT SAFETY INSTRUCTIONS recommended by Samsung, or sold with the monitor. Any CAUTION mounting of the monitor should follow Samsung’s instructions and should use a mounting accesso...
Page 4
USER'S MANUAL 18.Damage Requiring Service : Unplug this monitor from NOTE: This equipment has been tested and found tocomply the wall outlet and refer servicing to qualified service with the limits fo...
Page 5
USER'S MANUAL Contents Important Safety Instructions .................................................................... Unpacking .......................................................................
Page 6
USER'S MANUAL Unpacking Remove the package cover and place the product on a flat and secure surface or in the installation location. Check whether all the following devices and accessories are include...
Page 7
USER'S MANUAL Rear & Left Side View Left Side View Rear View Rear View Left Side View AC IN AUDIO-B AC power input. Audio-B input : Right (RED), Left (White) VIDEO-A IN AUDIO-A/S-VIDEO Com...
Page 8
USER'S MANUAL Remote Controller POWER Turns the Power On or Off. There will be a few seconds delay before display appears. Number button Changes the SYSTEM ID for remote controller. With the SYSTEM ID...
Page 9
USER'S MANUAL Connecting to External Devices. The product can be connected to an external device such as Camera, DVR,VCR, External Monitor, etc. CAMERA External MONITOR
Page 10
USER'S MANUAL OSD Menu Configurations Inputs can be set to Video A, Video B, S-Video, VGA No Signal Display mode. 1. Press the MENU and ENTER button. When there is no connection at the VGA and Video ....
Page 11
USER'S MANUAL PIP Size select (VGA mode only) If you didn't select VGA input, this menu is not avail- able. PIP : Off 1. Press the MENU and ENTER button. Source : S-video . Press the / and ENT...
Page 12
USER'S MANUAL Custom B. Picture Menu VGA mode : Contrast, Brightness Video mode Custom Contrast 81 Mode : Dynamic, Standard, Movie, Brightness 100 Custom Picture Mode : Movie Custom Color Ton...
Page 13
USER'S MANUAL Color Tone Under Scan : Over, Under VGA mode : Cool, Normal, Warm, Custom Picture Mode : Movie Clor Tone Custom Color Tone : Warm Normal Size : 4:3 Under Scan : Under Cust...
Page 14
USER'S MANUAL 1. Press the MENU and / button to select the Position (Image Lock) Picture menu. . Press the ENTER or button. Position 3. Press the / and ENTER button to select the Color control...
Page 15
USER'S MANUAL If you select PIP Off, this menu is not available. Custom : Bass, Treble, Balance 1. Press the MENU and / button to select the Sound Picture menu. Mode : Movie . Press the ENTER or...
Page 16
USER'S MANUAL D. Setup Menu Language 1. Press the MENU and / button to select the Setup menu. Setup . Press the ENTER or button. Language : English 3. Press the / and ENTER button to select ...
Page 17
USER'S MANUAL 1. Press the MENU and / button to select the Setup menu. . Press the ENTER or button. 3. Press the / and ENTER button to select the the Blue Screen. 4. Press the / and ENTER butt...
Page 18
USER'S MANUAL Specifications Model Name SMT-1721 SMT-1921 Sales Area World Wide Broadcasting System NTSC/PAL System Inch 17" 19" Resolution (Hx V) 180 X 104 Brightness(cd/m) Contrast 1000...
