Philips PHILIPS Philips BZV49 series Voltage regulator diodes handbook
Summary
These medium-power voltage regulator diodes are designed for general regulation functions in complex electronic systems. Housed in a compact SOT89 SMD package, the BZV49 series offers a robust selection of nominal working voltages from 2.4V to 75V and features an approximate ±5% tolerance range. This comprehensive data sheet provides critical technical specifications, including absolute maximum ratings, detailed electrical characteristics, and operation limits. Ideal for electronics engineers and designers integrating high-reliability power regulation solutions into their printed circuit boards.
Manual Details
| Brand | Philips |
|---|---|
| Pages | 12 |
| File Size | 57.86 KB |
| Published | June 06, 2026 |
