PHILIPS BB147 VHF Variable Capacitance Diode Data Sheet User Manual
Summary
A product specification for the BB147 VHF variable capacitance diode from Philips Semiconductors. The device features ultra-high capacitance ratio up to 43, excellent matching to 2% through direct matching assembly, and very small SOD323 plastic SMD package. Electrical characteristics include diode capacitance of 92-112pF at 0.5V, series resistance under 2.8Ω at 100MHz, and continuous reverse voltage rating of 30V. The manual covers limiting values, graphical data, and application guidance. Designed for RF engineers and circuit designers working on electronic tuning in television tuners and voltage-controlled oscillators in the VHF range.
Page 1 Text Content
查询BB147供应商
DISCRETE SEMICONDUCTORS
DATA SHEET
alfpage
BB147 VHF variable capacitance diode
Product specification Sep
