20W/40W, Filterless, Spread-Spectrum,

Mono/Stereo, Class D Amplifier General Description Features

The MAX9708 mono/stereo, Class D audio power amplifi- 2 x 21W Output Power in Stereo Mode er delivers up to 2 x 21W into an 8Ω stereo mode and (8Ω, THD = 10%) 1 x 42W into a 4Ω load in mono mode while offering up to

1 x 42W Output Power in Mono Mode

87% efficiency. The MAX9708 provides Class AB amplifi-

(4Ω, THD = 10%)

er performance with the benefits of Class D efficiency,

High Efficiency: Up to 87%

eliminating the need for a bulky heatsink and conserving

power. The MAX9708 operates from a single +10V to Filterless Class D Amplifier

+18V supply, driving the load in a BTL configuration. Unique Patented Spread-Spectrum Mode

The MAX9708 offers two modulation schemes: a fixed- Programmable Gain (+22d B, +25d B, +29.5d B, frequency modulation (FFM) mode, and a spread-spec- +36d B)

trum modulation (SSM) mode that reduces

High PSRR (90d B at 1k Hz)

EMI-radiated emissions. The MAX9708 can be synchro-

Differential Inputs Suppress Common-Mode

nized to an external clock from 600k Hz to 1.2MHz. A

Noise

synchronized output allows multiple units to be cascad-

Shutdown and Mute Control

ed in the system.

Integrated Click-and-Pop Suppression

Features include fully differential inputs, comprehensive

click-and-pop suppression, and four selectable-gain set- Low 0.1% THD+N

tings (22d B, 25d B, 29.5d B, and 36d B). A pin-program- Current Limit and Thermal Protection mable thermal flag provides seven different thermal

Programmable Thermal Flag

warning thresholds. Short-circuit and thermal-overload

SYNC Input/Output

protection prevent the device from being damaged

during a fault condition. Available in Thermally Efficient, Space-Saving Packages: 56-Pin TQFN and 64-Pin TQFP

The MAX9708 is available in 56-pin TQFN (8mm x 8mm x 0.8mm) and 64-pin TQFP (10mm x 10mm x 1.4mm)

Ordering Information

packages, and is specif ied over the extended -40°C to +85°C temperature range.

PART TEMP RANGE PIN-PACKAGE

Applications

MAX9708ETN+ -40°C to +85°C 56 TQFN-EP** T5688-3

LCD TVs PDP TVs

MAX9708ECB* -40°C to +85°C 64 TQFP-EP** C64E-6

Automotive PC/Hi Fi Audio Solutions

+Denotes lead-free package. *Future product—Contact factory for availability. **EP = Exposed paddle.Pin Configurations appear at end of data sheet.

Simplified Block Diagram

MAX9708 SYNCOUT SYNCOUT

FS1, FS2 FS1, FS2 MAX9708

SYNC SYNC

CHANNEL

AUDIO

CLASS D CLASS D

INPUT

MODULATOR MODULATOR

CHANNEL

GAIN VDIGITAL

OUTPUT GAIN

OUTPUT

CONTROL

MONO PROTECTION CONTROL

PROTECTION

G1, G2 G1, G2 TH0, TH1, TH0, TH1,

TH2 TEMP

TH2 TEMP

STEREO MODE MONO MODE
