CHAPTER ! Mechanical section
AMB-289/IP-420 INSTRUCTION MANUAL
* "Compact Flash(TM)" is the registered trademark of San Disk Corporation, U.S.A.
Page Summary Contents For Juki Automatic Sewing Machine AMB-289 User's Manual and User Guide (English)
Page 1
CHAPTER ! Mechanical section AMB-289/IP-420 INSTRUCTION MANUAL * "Compact Flash(TM)" is the registered trademark of San Disk Corporation, U.S.A.
Page 2
CONTENTS 1. SPECIFICATIONS ..........................................................................................Ⅰ–1 (1) Specifications ...............................................................
Page 3
2) Adjusting the moving knife thread separation nail......................................................................... Ⅰ–21 (5) Adjusting the wiper mechanism ......................................
Page 4
!. Mechanical section 1. SPECIFICATIONS (1) Specifications Model AMB-289 Computer-controlled, high-speed, single-thread, chainstitch, button-neck-wrapping Name of model machine Application Various but...
Page 5
(2) Shapes of buttons 1) Specifications for 4-holed and 2-holed buttons Needle used : ø 1.5 mm or more when using #12 to #16 A : Buttonhole diameter Needle used : ø 2 mm or more when using #16 to #18 ...
Page 6
3) Specifications for stay button Commendable dimension 1 mm or *1 less Outside Buttonhole Buttonhole Thickness diameter diameter pitch of button Type A 8.5mm 2.5mm 3.1mm 2.0mm Buttonhole diameter Typ...
Page 7
(3) Configuration AMB-289 consists of the following components. Power switch Machine head (AMB-289) Operation panel (IP-420) Control box (MC-640) Foot pedal Start switch Thread stand device Power swit...
Page 8
2. INSTALLATION DANGER : To prevent possible accidents caused by the fall of the sewing machine, perform the work by two persons or more when the machine is moved. (1) Set-up of the table 1) Fix contr...
Page 9
(2) Connecting the power source cord 1) Voltage specifications Power source specifications are indicated on the voltage indication seal. (3-phase type only) Fo r o the r t ype mach ines , power sou rc...
Page 10
(3) Changing the voltage of 100 / 200V DANGER : To prevent personal injuries caused by electric shock hazards or abrupt start of the sewing machine, carry out the work after turning OFF the power swit...
Page 11
(4) Installing the sewing machine main unit WARNING : To prevent possible accidents caused by the fall of the sewing machine, perform the work by two persons or more when the machine is moved. Adjust ...
Page 12
(6) Removing the fixed plate for transport Remove fixed screw 1 and remove fixed plate for transport 2. Fixed screw 1 and fixed plate for transport 2 are necessary when transporting with the machine h...
Page 13
(8) Installing the air regulator 1) Install filter installing plate 1 on the right side of the stand side support with screw 3. 2) Fix air regulator 2 on filter installing plate 1 with screw 4. 3) Fix...
Page 14
(9) Connecting the cords Perform the connection of the cords as shown in the figure below. Sewing machine head SDC circuit board Start switch Operation panel CN39 CN40 MAIN CN40 circuit CN41 board CN4...
Page 15
(10) Managing the cord 1) Slowly tilting the sewing machine, check that the cords are not forcibly pulled. 2) Fix the cords with cord setting plate 1 as shown in the figure. When you tilt the sewing m...
Page 16
(12) Installing the thread stand 1) Assemble the thread stand, and set it in the hole in the top right corner of the machine table. 2) Tighten locknut 1 to fix the thread stand. 3) When ceiling wiring...
Page 17
3. PREPARATION BEFORE OPERATION (1) Inserting the needle WARNING : To protect against possible personal injury due to abrupt start of the machine, be sure to start the following work after turning the...
Page 18
(3) Adjusting the stay (counter) button stopper WARNING : To protect against possible personal injury due to abrupt start of the machine, be sure to start the following work after turning the power of...
Page 19
(4) Replacing the button chuck WARNING : To protect against possible personal injury due to abrupt start of the machine, be sure to start the following work after turning the power off and ascertainin...
Page 20
(5) Set of the button neck wrapping When performing the button neck wrapping process of stay (counter) button, use the button neck wrapping attachment (accessories) 1. Groove Groove Loosen screws 2 an...
Page 21
4. ADJUSTMENT OF THE SEWING MACHINE (1) Adjusting the needle and the looper 1) Adjusting the needle bar height Use the timing gauge supplied as accessories. Loosen screw 1 and adjust so that plane A i...
Page 22
(2) Adjusting the position of the york slide 1) The position of york slide 1 has been factory- assembled so that the clearance between york slide 1 and the needle is longitudinally 0.2 to 0.4 and late...
Page 23
(3) Adjusting the needle and the needle guide 1) Adjusting the position of the needle and the throat plate Loosen screws 1 and adjust the throat plate so that the needle enters the center of the needl...
Page 24
(4) Adjusting the thread trimmer mechanism 1) Adjusting the position of the moving knife First adjustment Second adjustment 13 to 14 mm 3 to 5 mm [Waiting position] [Thread trimming position] 1. Loose...
Page 25
(5) Adjusting the wiper mechanism 1) Turn OFF the air, and draw wiper 1 until it goes no further. 2) Adjust wiper cylinder installing bases A 3. and B 4 with the respective setscrews 5 and 6 so that t...
Page 26
5. MAINTENANCE (1) Replacing the attachments 1) Replacing the button set pin (optional) When replacing button set pin 2, loosen knob 1. and replace it. However, when replacing the set pin with those b...
Page 27
3) Replacing the tongue stopper When using the standard 4-holed tongue (Part No. 25006602) of the former AMB-189N, replace the tongue stopper guide together. 1) Replacing the tongue Remove screws 1 an...
Page 28
(2) Replacing the fuse DANGER : 1. To avoid electrical shock hazards, turn OFF the power and open the control box cover after about five minutes have passed. 2. Open the control box cover after turnin...
Page 29
(3) Greasing parts WARNING : Turn OFF the power before starting the work so as to prevent accidents caused by abrupt start of the sewing machine. Periodically perform grease-up every 6 months as a sta...
Page 30
3) Apply grease to the york slide cam and the york slide triangle cam sections. • Tilt the machine head • Remove the looper cover. • Turning the hand pulley, apply grease to the lateral cam section. F...
Page 31
6. AIR CIRCUIT DIAGRAM
Page 32
7. DRAWING OF THE TABLE Pa rt o. C1(Full perip hery) hery) (1) Table C1(Full perip po t f ac in ril lin 3x ril lin ril lin 4x dr ill in g, ep th ril lin po t f ac in Pa in tin Pa in tin 6x 2 d ril lin...
Page 33
(2) Auxiliary table Pa rt o. ound R2 All-r 2- dr ill in ound R2 All-r
