C&K Y Series

4, 5 & 6 Tumbler Switchlocks

Features/Benefits Typical Applications Anti-static switch—exceeds Point-of-sale terminals 20 KV DCstatic resistance

Cash registers

Momentary models available

Computers

Wire leads and harnesses available

Patent No. 4,639,562

Models Available

Specifications Materials CONTACT RATING: Q contact material: 4 AMPS @ 125 V AC or LOCK: Zinc alloy with stainless steel facing, std. (4 & 5 tumbler lock 28 V DC; 2 AMPS @ 250 V AC (UL/CSA). See page M-9 for and 6 tumbler tubular lock). additional ratings.

KEYS: Two nickel plated brass keys, with code number, std.

ELECTRICAL LIFE: 10,000 make-and-break cycles at full load. (4 and 5 tumbler lock). Two die cast chrome plated zinc alloy

CONTACT RESISTANCE: Below 10 m Ω typ. initial @ 2-4 V DC, keys,std. (6 tumbler lock).

100 m A, for both silver and gold plated contacts. SWITCH HOUSING: Glass filled polyester (UL 94V-0). INSULATION RESISTANCE: 109 min. CONTACTS AND TERMINALS: Q contact material: Copper, silver

DIELECTRIC STRENGTH: 1,000 Vrms min. @ sea level. plated. See page M-9 for additional contact materials. INDEXING: 45º or 90º, 2-4 positions (4&5 tumbler switchlocks). MOUNTING NUT: Zinc alloy.

45º, 3 positions; or 90º, 2 positions (6 tumbler tubular MOUNTING CLIP: Steel, zinc plated. switchlocks).

DRESS NUT: Brass, nickel plated.

Other functions available, consult Customer Service Center.

TERMINAL SEAL: Epoxy.

STATIC RESISTANCE: Anti-static models exceed 20 KV DC static

resistance @ sea level, lock body to terminals. NOTE: Any models supplied with Q, B or G contact material are Ro HS compliant. For the latest information regarding Ro HS compliance, please go to: www.ittcannon.com/rohs.

MOUNTING TORQUE: 10 in./lbs.; 14 in./lbs max.

NOTE: Specifications and materials listed above are for switchlocks with standard options. For information on specific and custom switchlocks, consult Customer Service Center.

Build-A-Switch To order, simply select desired option from each category and place in the appropriate box. Available options are shown and described on pages M–4 through M–10. For additional options not shown in catalog, consult Customer Service Center.

Switch and Lock Function Y10013 SP, 45°, keypull pos. Keying

Y1011U SP, 90°, keypull pos. 1 & 2 Two nickel plated brass keys (4 &

Y1001U SP, 40°, keypull pos. 1 & 3 5 tumbler) or two die cast zinc alloy keys with

Y2001U DP, 40°, keypull pos. 1 & 3 chrome plating (6 tumbler) Y10082 SP, 40°, keypull pos. Two nickel plated brass keys with code on lock face

Y20082 DP, 40°, keypull pos.

Lock Type

Y100AA SP, 40°, keypull pos. 1, 2 & 3

4 Tumbler lock (YXO8 models)

Y200AA DP, 40°, keypull pos. 1, 2 & 3

4 Tumbler lock with detent

Y100AB SP, 40°, keypull pos. 1, 2, 3 & 4

6 Tumbler tubular lock

Y200AB DP, 40°, keypull pos. 1, 2, 3 & 4

5 Tumbler lock

Y10113 SP, 90°, keypull pos.

4 Tumbler lock with detent and anti-Static switch

Y20113 DP, 90°, keypull pos.

6 Tumbler tubular lock with anti-Static switch

Y1011C SP, 90°, keypull pos.2

Y2011C DP, 90°, keypull pos. Lock Finish Y2011U DP, 90°, keypull pos. 1 & 2 Stainless steel facing Y14173 SP, 90°, keypull pos. Gloss black facing

Terminations Contact Material

Y1417U SP, 90°, keypull pos. 1,2 & 3 Polished nickel facing

Solder lug with hole Silver

Y10812 SP, 40°, mom., keypull pos.

Solder lug with notch Gold

Y20812 DP, 45°, mom., keypull pos.

PC Thru-hole Gold over silver

Y19073 SP w/common, 90°, keypull pos.

Solder lug with hole

Y1907U SP w/common, 90°, keypull pos. 1, 2 & 3

(Y19OXX models only)

Y1900S SP w/common, 90°, keypull pos. 1, 2, 3 & 4 Seal

WC Wire lead

NONE No seal

Mounting/Lock Style

Epoxy seal

With nut With clip With removable dress nut and latch pawl With removable dress nut
