Dell G15 5510 Service Manual
Regulatory Model: P105F Regulatory Type: P105F002 August 2021 Rev. A03
Page Summary Contents For Dell G15 5510 Service ManualNote: The service manual part is not translated as it does not follow the document type rules. If a different rule were to apply to service manuals, please provide additional instructions accordingly.
Page 1
Dell G15 5510 Service Manual Regulatory Model: P105F Regulatory Type: P105F002 August 2021 Rev. A03
Page 2
Notes, cautions, and warnings NOTE: A NOTE indicates important information that helps you make better use of your product. CAUTION: A CAUTION indicates either potential damage to hardware or loss of d...
Page 3
Contents Chapter 1: Working inside your computer...................................................................................... Before working inside your computer.................................
Page 4
Installing the display assembly..................................................................................................................................33 Removing the display assembly..........
Page 5
Support Assist diagnostics............................................................................................................................................... System diagnostic lights.........
Page 6
Working inside your computer Before working inside your computer NOTE: The images in this document may differ from your computer depending on the configuration you ordered. Before you begin Steps 1. S...
Page 7
When disconnecting cables, keep them evenly aligned to avoid bending the connector pins. When connecting cables, ensure that the ports and the connectors are correctly oriented and aligned. CAUTION: P...
Page 8
use wireless wrist straps. Always be aware that the internal wires of a wrist strap are prone to damage from normal wear and tear, and must be checked regularly with a wrist strap tester in order to a...
Page 9
Removing and installing components NOTE: The images in this document may differ from your computer depending on the configuration you ordered. Recommended tools The procedures in this document may req...
Page 10
Table 1. Screw list (continued) Component Secured to Screw type Quantity Screw image SSD2 Solid-state drive bracket M2x4 Wireless-card bracket System board M2x4 Power-adapter port Palm-rest and keyboa...
Page 11
Removing and installing components
Page 12
Removing and installing components
Page 13
Steps 1. Loosen the four captive screws that secure the base cover to the palm-rest and keyboard assembly. 2. Remove the four screws (M2x6) that secure the base cover to the palm-rest and keyboard ass...
Page 14
Removing and installing components
Page 15
Steps 1. Connect the battery cable to the system board, if the battery cable had been previously disconnected. 2. Align the screw holes on the base cover with the screw holes on the palm-rest and keyb...
Page 16
2. Lift the thermal shield off the palm-rest and keyboard assembly. 3. Slide and lift the solid-state drive off the slot on the system board. Installing the solid-state drive in SSD slot one Prerequis...
Page 17
2. Follow the procedure in After working inside your computer. Removing the solid-state drive in SSD slot two Prerequisites 1. Follow the procedure in Before working inside your computer. 2. Remove th...
Page 18
About this task NOTE: Your computer has two solid-state drive slots. The solid-state drive 1 slot is located at the bottom left corner of the system board and the solid-state drive 2 slot is located a...
Page 19
If you are replacing the solid-state drive of a different form factor other than the one removed, see the following procedure to move the location of the screw mount. Steps 1. Remove the screw mount f...
Page 20
Steps 1. Remove the screw (M2x4) that secures the wireless card to the USB board. 2. Lift the bracket that secures the wireless card to the system board. 3. Disconnect the antenna cables from the wire...
Page 21
Steps 1. Connect the antenna cables to the wireless card. The following table provides the antenna-cable color scheme for the wireless card supported by your computer. Table 2. Antenna-cable color sch...
Page 22
Memory module Removing the memory module Prerequisites 1. Follow the procedure in Before working inside your computer. 2. Remove the base cover. About this task The following image indicates the locat...
Page 23
Steps 1. Align the notch on the memory module with the tab on the memory-module slot. 2. Slide the memory module firmly into the slot at an angle. 3. Press the memory module down until it clicks into ...
Page 24
Ensure any screws during the servicing of this product are not lost or misplaced, to prevent accidental puncture or damage to the battery and other system components. If the battery gets stuck inside ...
Page 25
About this task The following image indicates the location of the battery and provides a visual representation of the installation procedure. Steps 1. At an angle, slide the battery into the slot on t...
Page 26
2. Follow the procedure in After working inside your computer. Touchpad Removing the touchpad Prerequisites 1. Follow the procedure in Before working inside your computer. 2. Remove the base cover. 3....
Page 27
Steps 1. Align and place the touchpad into the slot on the palm-rest and keyboard assembly. 2. Replace the seven (M2x2) screws that secure the touchpad and touchpad bracket to the palm-rest and keyboa...
Page 28
About this task The following image indicates the location of the I/O board and provides a visual representation of the removal procedure. Steps 1. Turn the system board over. 2. Remove the two screws...
Page 29
Steps 1. Insert the I/O board at a 45 degree angle into the slot on the system board. 2. Align the screw holes on the I/O board with the screw holes on the system board. 3. Install the two screws (M2x...
Page 30
About this task The following image indicates the location of the speakers and provides a visual representation of the removal procedure. Steps 1. Note the routing of the cable that connects the left ...
Page 31
Steps 1. Using the alignment posts and rubber grommets, place the speakers in the slots on the palm-rest and keyboard assembly NOTE: If the rubber grommets are pushed out of the speakers when removing...
Page 32
Steps 1. Remove the two screws (M2.5x5) that secure the rear cover to the palm-rest and keyboard assembly. 2. Remove the two screws (M2x2) that secure the rear cover to the system board. 3. Push the r...
Page 33
Steps 1. Slide the rear cover towards the system board till it snaps into place. 2. Align the screw holes on the rear cover with the screw holes on the palm-rest and keyboard assembly. 3. Replace the ...
Page 34
2. Route the antenna cable and display cable through the routing guides on the palm-rest and keyboard assembly and to the top side of the computer and along the left of the power adapter port. 3. Repl...
Page 35
Steps 1. Peel the tapes that secure the antenna cables to the system board. 2. Note the routing of the antenna cable and display cable, and remove the antenna cables from the left fan. 3. Peel the tap...
Page 36
Power-adapter port Removing the power-adapter port Prerequisites 1. Follow the procedure in Before working inside your computer. 2. Remove the base cover. 3. Remove the rear cover. About this task The...
Page 37
Steps 1. Remove the two screw (M2x4) on the power-adapter port-bracket that secures the power-adapter port to the palm-rest and keyboard assembly. 2. Remove the power-adapter port-bracket from the pow...
Page 38
Steps 1. Place the power-adapter port into the slot and adhere the power-adapter port cable on the system board. 2. Connect the power-adapter port cable to the system board. 3. Align and place the pow...
Page 39
Steps 1. Peel the tapes that secures the wireless-card cable to the system board. 2. Note the routing of the wireless-card cable and remove the wireless-card cable from the right fan. 3. Disconnect th...
Page 40
Steps 1. Align and place the right fan on the palm-rest and keyboard assembly. 2. Replace the two (M2x6) screws to secure the right fan to the palm-rest and keyboard assembly. 3. Connect the left-fan ...
