Setting up DL4300 Appliance Introduction The Dell DL4300 appliance is the latest generation of backup-to-disk appliance powered by Rapid Recovery software. The appliance allows: Scalable storage capab...
Page 6
NOTE: Additional storage can be added through expansion shelves (Dell Storage MD1400). Additional storage can be added to any model, however the Standard Edition has a maximum capacity of 60 TB and th...
Page 7
Figure 1. Setting the Power Vault MD1400 storage enclosure configuration switch 1. configuration switch Connecting the storage enclosure to the system Connect the data cable from the Power Edge RAID C...
Page 8
Multichain configuration Figure 3. Multichain configuration Multichain configuration supports up to four enclosures. The first two enclosures are daisy-chained with one of the enclosures connected to ...
Page 9
Initial software setup When you turn on the appliance for the first time, and change the system password, the App Assure Appliance Configuration Wizard runs automatically. 1. After you turn on the sys...
Page 10
NOTE: The App Assure Appliance Configuration wizard configures network interfaces as individual ports (non- teamed). To improve ingest performance, you can create a larger ingest channel by teaming NI...
Page 11
The Configure SNMP Settings page is displayed. Configuring SNMP settings Simple Network Management Protocol (SNMP) is a commonly used network management protocol that allows SNMP-compatible management...
Page 12
4. Continue the configuration process by Provisioning storage DL Appliance Configuration Wizard NOTE: You see the DL Appliance Configuration Wizard only when you upgrade your appliance using the lates...
Page 13
To assign the network connection manually, select Set manually IPV6 address and enter the following details: IPv6 Address Subnet prefix length Default Gateway 7. To enable NIC teaming, select Enable N...
Page 14
To enable system SNMP alerts, select Enable system SNMP alerts. 1. In SNMP Community, enter one or more SNMP community names. Use commas to separate multiple community names. 2. In SNMP Trap destinati...
Page 15
Storage provisioning Your appliance allows you to provision its internal storage to create Virtual disks (VDs) to host repositories and Virtual Standby, archives or other purposes. 1. On the Storage P...
Page 16
Text Box Description …and then keep one recovery Provides a more granular level of retention. It is used as a building block to further define how point per week for n long recovery points are maintai...
Page 17
Creating the RASR USB key To create a RASR USB key: 1. Navigate to the Appliance tab. 2. Using the left pane navigation, select Appliance → Backup. Create RASR USB Drive window is displayed. NOTE: Ins...
Page 18
10. Select the Factory Reset option. This option will recover the operating system disk from the factory image. 11. Click Next. The following warning message is displayed in a dialog box: This operati...
Page 19
of the storage remaining after creating the Rapid Recovery repository. Space can be allocated for standby VMs only on the appliances that are provisioned to host virtual machines. Using the Rapid Reco...
Page 20
b. In the Create Volume dialog box, specify the following information for a new disk volume Volume name, Controller, Enclosure, RAID type, and Size. The Controller available space is displayed by defa...
Page 21
Post installation tasks After completing the DL Appliance Configuration Wizard perform the following procedures to ensure that your backup appliance and the servers that the appliance is backing up ar...
Page 22
NOTE: Ensure that the Internet Explorer Enhanced Security Configuration is turned on when you access the Core Web Console either locally or remotely. To turn on the Internet Explorer Enhanced Security...
Page 23
To encrypt agent snapshot data: 1. From the App Assure Core, click Configuration → Manage → Security. 2. Click Actions, and then click Add Encryption Key. The Create Encryption Key page is displayed. ...
Page 24
Text Box Description Email Enter information for the body of the template that describes the event, when it occurred, and the severity. 5. Click Send Test Email and review the results. 6. After you ar...
Page 25
Preparing to protect your servers Overview To protect your data using DL 4300, you need to add the workstations and servers for protection in the Core Console; for example, your Exchange server, SQL S...
Page 26
4. On the Connection page, enter the information about the machine to which you want to connect as described in the following table, and then click Next. Table 6. Machine connection settings Text Box ...
Page 27
If the prerequisite files do not exist, the Rapid Recovery Agent Installer identifies which files are needed and displays the results accordingly; for example, CRT 2013 (x64) ENU (distributable code f...
Page 28
If it is not installed, you can get a copy from microsoft.com. 2. Install the agent: a. On your appliance, share the directory C:\Program Files\App Recovery to the client(s) you plan to back up. b. On...
Page 29
3. Enter the host information and logon credentials as described in the following table. Table 8. v Center/ESX(i) connection settings Text Box Description Host The name or IP address of the VMware v C...
Page 30
Because the various supported Linux distributions use different package managers for online installation, the procedure for installing, upgrading, or removing Agent on any supported Linux OS depends o...
Page 31
Restart the Linux machine The instructions for installing the Agent software on a Linux machine differ slightly depending on the Linux distribution you are using. For more information about preparing ...
Page 32
The rapidrecovery-agent requires: dkms, gcc, make, kernel-headers-‘uname-r‘ kernel-devel-‘uname-r‘, nbd-dkms, libblkid, pam, pcre The rapidrecovery-mono requires: glibc >=2.11 For SUSE Linux Enterp...
Page 33
NOTE: This procedure applies to a Linux machine that is connected to the internet. For offline installation of Rapid Recovery Agent on any Linux machine, see Installing the Agent software on offline L...
Page 34
Installing the Agent software on offline Linux machines This task requires access to an online Linux machine, removable storage media, and access to the final offline Linux machine. If App Assure Agen...
Page 35
Installing the Agent software on Windows Server Core Edition machines Complete the steps in the following procedure to install the Agent software on a Windows Server Core machine. NOTE: The following ...
Page 36
Kernels compatible for module installation: 0 - linux-image-3.16.0.23-generic 1 - linux-image-3.16.0.31-generic 2 - linux-image-3.16.0.33-generic 3 - linux-image-3.16.0.34-generic Input indices of the...
Page 37
Text Box Description User name The user name used to connect to this machine; for example, Administrator (or, if the machine is in a domain, [domain name]\Administrator). Password The password used to...
Page 38
If you already have repository information configured, and you selected the Advanced option in Step 1, then the Encryption page appears. Proceed to Step 13. 12. Optionally, on the Encryption page, to ...
Page 39
3. Open a command line interface on the appliance. 4. Run the command ping <IP address of client>. 5. Depending on the result, do one of the following: If the client does not reply to the ping, ...
Page 40
4. Complete the installation by going through the installation wizard. Creating the NIC team NOTE: It is recommended not to use the native teaming interface in Windows 2012 Server. The teaming algorit...
