Summary
Optimize your Dell PowerVault MD3000 and MD3000i storage arrays with this comprehensive guide to best practices. Designed for system administrators, this resource provides deep insights into achieving peak performance. Learn how to correctly select RAID levels (including RAID 5 and RAID 6), calculate optimal stripe and segment sizes, tune cache settings, and balance I/O distribution across your array for rock-solid data management.
Page 1 Text Content
POWERVAULT MD3000 AND MD3000i
ARRAY TUNING BEST PRACTICES dell.com/Power Vault
Page Summary Contents For Dell ARRAY TUNING Best Practices Guide User Manual
Page 1
POWERVAULT MD3000 AND MD3000i ARRAY TUNING BEST PRACTICES dell.com/Power Vault
Page 2
Dell™ Power Vault MD3000 and MD3000i Array Tuning Best Practices DISCLAIMER THIS WHITE PAPER IS FOR INFORMATIONAL PURPOSES ONLY, AND MAY CONTAIN TYPOGRAPHICAL ERRORS AND TECHNICAL INACCURACIES. THE CO...
Page 3
Dell™ Power Vault MD3000 and MD3000i Array Tuning Best Practices Table of Contents 1 AUDIENCE AND SCOPE 4 2 PERFORMANCE TUNING OVERVIEW.................................................................
Page 4
Dell™ Power Vault MD3000 and MD3000i Array Tuning Best Practices 1 Audience and Scope This document is intended to guide MD3000 and MD3000i customers through the advanced processes behind tuning their...
Page 5
Dell™ Power Vault MD3000 and MD3000i Array Tuning Best Practices The answers include: • “It depends…” There are no absolute answers. Each environment is unique and the correct settings depend on the u...
Page 6
Dell™ Power Vault MD3000 and MD3000i Array Tuning Best Practices • Profile of mean I/O direction; this is usually the ratio of Reads to Writes 4 Configuring the MD3000/MD3000i There are two ways to co...
Page 7
Dell™ Power Vault MD3000 and MD3000i Array Tuning Best Practices Physical disk cost is not the only factor that influences the decision on which RAID level is most appropriate for a given application....
Page 8
Dell™ Power Vault MD3000 and MD3000i Array Tuning Best Practices 4.1.1 Selecting a RAID Level - High Write Mix Scenario In random I/O applications with a >10% mix of write operations and a low degr...
Page 9
Dell™ Power Vault MD3000 and MD3000i Array Tuning Best Practices • To optimize for data transfer rate, multiply the number of physical data disks by the segment size to equal the I/O size. However, th...
Page 10
Dell™ Power Vault MD3000 and MD3000i Array Tuning Best Practices traffic virtual disks share a disk group, even with purely sequential usage models, the disk group I/O behavior becomes increasingly ra...
Page 11
Dell™ Power Vault MD3000 and MD3000i Array Tuning Best Practices first 128Ki B of an I/O is written to the first drive, the next 128Ki B to the next drive, and so on with a total stripe size of 512Ki ...
Page 12
Dell™ Power Vault MD3000 and MD3000i Array Tuning Best Practices 4.6 Cache Settings Read-ahead cache can be configured in the MDSM and through the CLI. The MDSM has only the defaults to work with, whi...
Page 13
Dell™ Power Vault MD3000 and MD3000i Array Tuning Best Practices 4.6.3 Setting the Storage Array Cache Block Size Configured through the CLI – This command is available at the storage array level and ...
Page 14
Dell™ Power Vault MD3000 and MD3000i Array Tuning Best Practices 4.7 Tuning Using Array Performance Data 4.7.1 Collecting Performance Statistics The state Capture Data.txt and performance Statistics.c...
Page 15
Dell™ Power Vault MD3000 and MD3000i Array Tuning Best Practices Figure 2: First Generation Firmware - RAID Level. File: state Capture Data.txt Virtual Disk Unit 0 Configuration Volume Type: 13+1 RAID...
Page 16
Dell™ Power Vault MD3000 and MD3000i Array Tuning Best Practices to how tightly the variance of sequential or random data access is contained within the volume. This can be purely random across an ent...
Page 17
Dell™ Power Vault MD3000 and MD3000i Array Tuning Best Practices In the first generation of firmware (see Figure 5), this can be determined from the ‘Avg. Blocks’ row which represents the average I/O ...
Page 18
Dell™ Power Vault MD3000 and MD3000i Array Tuning Best Practices In addition, the state Capture Data.txt file provides a more granular method for determining the distribution of I/O within stripes and...
Page 19
Dell™ Power Vault MD3000 and MD3000i Array Tuning Best Practices Figure 8: Second Generation Firmware– Stripe distribution. File: state Capture Data.txt Volume 0 Attributes: Volume Type: RAIDVolume Us...
Page 20
Dell™ Power Vault MD3000 and MD3000i Array Tuning Best Practices RMW, or Read-Modify-Write, is the second-best write algorithm available for RAID 5 and 6. A RMW occurs when a quantity of bits, smaller...
Page 21
Dell™ Power Vault MD3000 and MD3000i Array Tuning Best Practices Figure 10: Second Generation Firmware - Write Algorithms Volume 1 Attributes: Volume Type: RAIDVolume User Label: My RAID5vd Block Size...
Page 22
Dell™ Power Vault MD3000 and MD3000i Array Tuning Best Practices For a complete list of commands and instructions on using the CLI Performance Monitor, refer to the Dell™ Power Vault™ Modular Disk Sto...
Page 23
Dell™ Power Vault MD3000 and MD3000i Array Tuning Best Practices 5 Considering the Host Server(s) 5.1 Host Hardware Platform 5.1.1 Considering the Server Hardware Architecture Available bandwidth depe...
Page 24
Dell™ Power Vault MD3000 and MD3000i Array Tuning Best Practices Figure 11: MD3000i Advanced IPv4 Settings: VLAN, QOS, Jumbo Frames Support 5.1.3 Sharing Bandwidth with Multiple SAS HBAs Each SAS wide...
Page 25
Dell™ Power Vault MD3000 and MD3000i Array Tuning Best Practices used at certain times, providing a point-to-point raw wire speed of up to 12Gb/s. Please note that this raw speed does not take into ac...
Page 26
Dell™ Power Vault MD3000 and MD3000i Array Tuning Best Practices Microsoft provides the diskpar.exe utility as part of the Microsoft Windows 2000 Resource Kit, which was renamed to diskpart.exe in Mic...
Page 27
Dell™ Power Vault MD3000 and MD3000i Array Tuning Best Practices Appendix A: Obtaining Additional Performance Tools Table 3 shows a number of widely available tools, benchmarks, and utilities. Some of...
Page 28
Dell™ Power Vault MD3000 and MD3000i Array Tuning Best Practices Appendix B: System Troubleshooting For information about troubleshooting MD3000 and MD3000i storage arrays, refer to the “Troubleshooti...
Page 29
Dell™ Power Vault MD3000 and MD3000i Array Tuning Best Practices Appendix C: References Dell™ Power Vault™ Modular Disk Storage Manager CLI Guide, http://support.dell.com/support/edocs/systems/md3000/...
Page 30
Dell™ Power Vault MD3000 and MD3000i Array Tuning Best Practices Appendix D: Glossary of Terms Term Definition Burstiness A data traffic property defined as the ratio of the peak I/O rate to the avera...
Page 31
Dell™ Power Vault MD3000 and MD3000i Array Tuning Best Practices Term Definition directly on the drive in lieu of using an SATA interposer. RAID Redundant Array of Inexpensive Disks RAID 0 RAID Level ...
Page 32
Dell™ Power Vault MD3000 and MD3000i Array Tuning Best Practices Term Definition by t10.org Segment A segment is the data written to one drive in a virtual disk group stripe before writing data to the...
