Containerizing HPC Applications with Singularity Authors: Rengan Xu, Frank Han, Nishanth Dandapanthula. HPC Innovation Lab. October 2017

Overview In this blog, we will give an introduction to Singularity containers and how they should be used to containerize HPC applications. We run different deep learning frameworks with and without Singularity containers and show that there is no performance loss with Singularity containers. We also show that Singularity can be easily used to run MPI applications.

Introduction to Singularity Singularity is a container system developed by Lawrence Berkeley Lab to provide container technology like Docker for High Performance Computing (HPC). It wraps applications into an isolated virtual environment to simplify application deployment. Unlike virtual machines, the container does not have a virtual hardware layer and its own Linux kernel inside the host OS. It is just sandboxing the environment; therefore, the overhead and the performance loss are minimal. The goal of the container is reproducibility. The container has all environment and libraries an application needs to run, and it can be deployed anywhere so that anyone can reproduce the results the container creator generated for that application.

Besides Singularity, another popular container is Docker, which has been widely used for many applications. However, there are several reasons that Docker is not suitable for an HPC environment. The following are various reasons that we choose Singularity rather than Docker:

 Security concern. Because of Docker daemon, a user inside the Docker container is able to obtain root access on the host and then may act maliciously on the supercomputing cluster. In contrast, Singularity solves this by running the container with the user’s credentials. The access permissions of a user are the same both inside the container and outside the container. Thus, a non-root user cannot change anything outside of his/her permission.

 HPC Scheduler. Docker does not support any HPC job scheduler, but Singularity integrates seamlessly with all job schedulers including SLURM, Torque, SGE, etc.

 GPU support. Docker does not support GPU natively. Nvidia Docker is a GPU-enabled Docker container, but it preinstalls various software that a user may not need. Singularity is able to support GPUs natively. Users can install whatever CUDA version and software they want on the host which can be transparently passed to Singularity.

MPI support. Docker does not support MPI natively. So if a user wants to use MPI with Docker, a MPI-enabled Docker needs to be developed. If a MPI-enabled Docker is available, the network stacks such as TCP and those needed by MPI are private to the container which makes Docker containers not suitable for more complicated networks like Infiniband. In Singularity, the user’s environment is shared to the container seamlessly.
