Congratulations on choosing our product! Thank you very much for purchasing our product. To obtain the best performance from this unit and to ensure safe and correct operation, please read this Instru...
Page 4
Table of Contents Table of Contents......................................... Editing Embroidery Designs............................ Selecting patterns Before Use Moving patterns What you can do with t...
Page 5
Before Use What you can do with this software This software provides digitizing and editing capabilities, allowing you the creative freedom to design original embroidery. Easily combine images and tex...
Page 6
Before Use Optional Supply Original card Note: The only original cards that can be used with this USB card writer module are those like the one enclosed or optional original cards of the same type. Me...
Page 7
Before Use Installation Please Read Before Installation Before beginning the installation, check that the computer meets the system requirements. In order to install the software on Windows® Operating...
Page 8
Before Use Installing the Software This section describes how to install the application software. Note: If the installation is interrupted or not performed as described, the software will not be inst...
Page 9
Before Use Windows Vista™ users only After a short while, the Auto Play dialog box automatically appears. Memo: If the Auto Play Dialog does not automatically start up: 4) Click the Start button. 5) C...
Page 10
Before Use 4. Select the desired language, and then click OK. The Install Shield Wizard starts up, and the first dialog box appears. 5. Click Next to continue with the installation. A dialog box appea...
Page 11
Before Use 6. Click Next to install the application into the selected folder. When the installation is completed, the following dialog box appears. 7. Click Finish to complete the installation of the ...
Page 12
Before Use Technical Support Contact Technical Support if you have a problem. Please check the company web site (http://www.brother.com/) to find the technical Support in your area. To view the FAQ an...
Page 13
Tutorial Understanding the Window and Using Tools The default value for the design page size in this example is 100 × 100 mm. Title bar Menu bar Provides access to the functions. Toolbar Provides shor...
Page 14
Tutorial Adding Text and Converting an Image to an Embroidery Design (Auto Punch Function) In this section, we are going to use the Auto Punch function to automatically create an embroidery pattern fr...
Page 15
Tutorial Specify the size. For this example, use the default size of 10.0 mm. Type in “Tulip” using the keyboard. Memo: Memo: The value indicates the height of the To move the dialog box to a more cha...
Page 16
Tutorial Click the text , and then drag a Memo: handle to adjust the selected text to the If you want to edit the entered text, click desired size. on the Tool Box, click the text to Memo: select it, ...
Page 17
Tutorial Step 2 Adjusting the text layout Memo: If you want to change the text arrangement Next, we will change the text arrangement. afterwards, click on the Tool Box, click the text to select it, an...
Page 18
Tutorial Select the sample file tulip.bmp, and then click Open, or double-click the file’s icon. Move the pointer over the selected image, and The image appears in the Design Page. then drag the image...
Page 19
Tutorial Convert the image to an embroidery Step 5 Specifying the sewing pattern. color and direction Next, we will change the sewing color and direction. Change the region color Check the Result View...
Page 20
Tutorial Specify the color. For this example, click to select HARVEST GOLD, and then click OK. Memo: To move the dialog box to a more convenient place on the screen, move the pointer over the title ba...
Page 21
Tutorial Step 6 Changing the sewing Memo: order When a frame in the Sewing Order / Color Next, we will change the sewing order so that the dialog box is selected, the buttons at the black text and the...
Page 22
Tutorial Step 8 Saving the embroidery design Once the embroidery design is finished, you may want to save it in order to retrieve it later. Click Display, then Realistic Preview, or click on the toolb...
Page 23
Tutorial The following message appears. Step 9 Transferring the design to an original card By writing a design to a media that can be used in your sewing machine and transferring it to your sewing mac...
Page 24
Automatically Converting an Image to an Embroidery Pattern Importing Image Data Importing image data Memo: Double-clicking the file name also opens the file and closes the dialog box. To quit the oper...
Page 25
Automatically Converting an Image to an Embroidery Pattern 1. Check that the scanner or other TWAIN device Memo: is correctly connected to your computer. If the image currently displayed in the 2. Cli...
Page 26
Automatically Converting an Image to an Embroidery Pattern Changing the Image Settings Moving an image: Changing the display of the 1. Move the pointer over the image. background image The shape of th...
Page 27
Automatically Converting an Image to an Embroidery Pattern Automatically Converting an Image to an Embroidery Pattern (Auto Punch) The Auto Punch gives step-by-step instructions for converting an imag...
Page 28
Automatically Converting an Image to an Embroidery Pattern 6. If necessary, in the Omit Colors list, click the colors to select whether or not they will be sewn. Memo: Colors that are crossed out are ...
Page 29
Arranging Embroidery Designs Opening/Importing Embroidery Designs Creating a new embroidery Note: If a .pes file created with PE-DESIGN design version 7 or earlier is opened with this software, the me...
Page 30
Arranging Embroidery Designs 3. To view the contents of the .pes files in the 4. To open a file, select it, and then click Open, currently selected folder, click Browse. or double-click the file’s ico...
Page 31
Arranging Embroidery Designs 3. To view the contents of the files in the Importing embroidery currently selected folder, click Browse. design files A Browse dialog box similar to the one shown below a...
Page 32
Arranging Embroidery Designs 4. To import a design, select it, and then click Import, or double-click the file’s icon. The embroidery design is displayed in the Design Page. Note: When importing desig...
Page 33
Arranging Embroidery Designs Specifying the Design Page Size and Color The color and size of the Design Page in addition to the color of the background can be changed. You can select a Design Page siz...
Page 34
Arranging Embroidery Designs Saving the Image Data The image can be saved as a file or output to the Clipboard. Saving as a file 1. Click Image, then Output, then to File. A dialog box similar to the ...
Page 35
Arranging Embroidery Designs Editing Embroidery Designs Selecting patterns in the created Selecting patterns order With selected, press the key to select Tab To apply settings to an existing pattern, ...
Page 36
Arranging Embroidery Designs 3. Drag the handle to adjust the selected Memo: pattern(s) to the desired size. To move the pattern horizontally or Memo: vertically, hold down the key while dragging it. ...
Page 37
Arranging Embroidery Designs 4. Drag the rotation handle clockwise or counterclockwise to rotate the pattern in 1° increments. Memo: To rotate the pattern in 15° increments, hold down the key while dr...
Page 38
Arranging Embroidery Designs Adding Text 4. Type the text. Entering Text Memo: Press the key to enter a new line Enter of text. 1. Click on the Tool Box. You can also enter a character by selecting it...
Page 39
Arranging Embroidery Designs The available fonts and the types of Selecting text attributes characters available with each font are listed below. Font Use this selector to select a font for the text. ...
Page 40
Arranging Embroidery Designs Built-in Fonts Editing entered text Uppercase letters of the English alphabet Lowercase letters of the English Text that has been entered can easily be edited. alphabet 1....
