Page 1
vehicle guide XMC-10A
Page 2
Ta bl of on te nt Table of Contents Congratulations .........................................................................3 FCC Information ............................................................
Page 3
Congratulations Congratulations Thank you for purchasing the Audiovox Xpress XM® Satellite Radio Vehicle Kit. You are one step closer to experiencing the latest innovation in XM Satellite Radio. XM Sa...
Page 4
FC In fo rm at io FCC Information Please note that the power cable that has been supplied with your device is supplied with permanently attached ferrite beads at each end. It is the responsibility of ...
Page 5
autions and W arnings Cautions and Warnings 1. Do not install the XMC-10A vehicle cradle in a position that hinders your view through the windshield, or obstructs viewing of the dashboard indicators a...
Page 6
Co nt en ts Contents XMC-10A Install Manual Cradle XMC-10A 1 pc. Antenna and Antenna Cable Exit Plug 1 pc. Cassette Adapter 1pc. 12 Volt-to-5 Volt DC Power Adapter 1 pc.
Page 7
Contents Contents XMC-10A (Cont) ACCESSORY KIT, MOUNTING Alcohol Cleaning Pad, Surface Cleaning Pad, Instruction Sheet, Swivel Bracket. OPTIONAL (sold separately) Audio Cable FM Direct Adapter (P/N SA...
Page 8
In st al la tio n/ iri ng re ca ut io ns Installation/Wiring Precautions 1. To prevent a short-circuit, be sure to turn off the ignition and remove the negative (-) battery cable prior to installation...
Page 9
Setting U p and Installing Your K it Setting Up and Installing Your Kit NOTE: The XM signal can be received and processed virtually anywhere as long as there are no obvious satellite signal obstructio...
Page 10
Se tti ng an In st al lin Yo ur it Interconnect Diagram XMC-10A CRADLE NOTE: (LEFT SIDE VIEW) 1. IF THE XMC-10A IS INSTALLED USING THE OPTIONAL XMFM-1 FM DIRECT ADAPTER, DO NOT CONNECT AN AUDIO CABLE ...
Page 11
Setting U p and Installing Your K it Interconnect Diagram (Cont) XMC-10A CRADLE (REAR VIEW) XM ANTENNA XMC-10A CRADLE (RIGHT SIDE VIEW) OPTIONAL SURE CONNECT KIT XMSC1 (SOLD SEPARATELY) OPTIONAL SAT-R...
Page 12
Se tti ng an In st al lin Yo ur it CAUTION: Do not install the swivel bracket on a leather or fabric surface, or in a position that could impair your vision, block air bag(s) or obstruct vehicle dashb...
Page 13
Setting U p and Installing Your K it e. Remove the plastic liner from the adhesive backing on the bracket, and fix the base in position on the surface; make sure the mounting pad is accurately positio...
Page 14
Se tti ng an In st al lin Yo ur it SIDE (HORIZONTAL) VERTICAL MOUNTING MOUNTING CONFIGURATION CONFIGURATION SWIVEL ADJUSTMENT SCREW XMC-10A CRADLE ASSEMBLY PLASTIC LINER AND SWIVEL SCREW HOLES (2) ADH...
Page 15
Setting U p and Installing Your K it 3. Using Other Manufacturer’s Mounts The XMC-10A Cradle can also be installed using other manufacturer’s mounts; the mounting plate provisions on the rear and bott...
Page 16
Se tti ng an In st al lin Yo ur it RECEIVER NOTCH Xpress XM Xpress XM RECEIVER SYSTEM RECEIVER CONNECTOR REAR VIEW RAISED DETENT CRADLE CONNECTOR XMC-10A FRONT VIEW GUIDE PIN SYSTEM CONNECTOR
Page 17
Setting U p and Installing Your K it 5. Connection Options The Xpress Receiver and Cradle provide an audio output signal in three ways: a. FM Modulator - When using the XMC-10A cradle with the FM modu...
Page 18
Se tti ng an In st al lin Yo ur it e. Xpress Cassette Adapter -The XM Xpress Cassette Adapter offers an additional audio connection option by utilizing your existing vehicle’s in-dash cassette deck. X...
Page 19
Setting U p and Installing Your K it Xpress Cassette Adapter Installation. Installation is simple. 1.) Plug the end jack (1) into the XM Xpress Car Cradle’s audio output (2). 2.) Insert the cassette a...
Page 20
Se tti ng an In st al lin Yo ur it 6. Installation Guidelines Step 1. First, determine the proper location for your XM satellite radio antenna based on the following criteria for your specific vehicle...
Page 21
Setting U p and Installing Your K it c. Avoid kinking, crimping, twisting or chafing the cable. Use pre-existing wire channels when possible. d. For option 1 and rear mounting locations, route the cab...
Page 22
Se tti ng an In st al lin Yo ur it Step 2. Once you have plugged the power and antenna jacks into the vehicle cradle, secure the cables with tape or wire ties to allow for a clean appearance. For exam...
Page 23
NOTES
Page 24
ar ra nt 12 MONTH LIMITED WARRANTY AUDIOVOX ELECTRONICS CORPORATION (the Company) warrants to the original retail purchaser of this product that should this product or any part thereof, under normal u...
Page 25
arranty THE EXTENT OF THE COMPANY'S LIABILITY UNDER THIS WARRANTY IS LIMITED TO THE REPAIR OR REPLACEMENT PROVIDED ABOVE AND, IN NO EVENT, SHALL THE COMPANY'S LIABILITY EXCEED THE PURCHASE PRICE PAID ...
