2.7 V to 5.25 V, Micropower, 8-Channel, 125 k SPS, 12-Bit ADC in 16-Lead TSSOP

AD7888

FEATURES FUNCTIONAL BLOCK DIAGRAM

Specified for VDD of 2.7 V to 5.25

Flexible Power/Throughput Rate Management

AD7888

Shutdown Mode: 1 A Max AIN1

Eight Single-Ended Inputs MUX T/H

Serial Interface: SPI™/QSPI™/MICROWIRE™/DSP Compatible

16-Lead Narrow SOIC and TSSOP Packages REF

APPLICATIONS

REF IN/REF OUT BUF

Battery-Powered Systems (Personal Digital Assistants, Medical Instruments, Mobile Communications)

CHARGE

Instrumentation and Control Systems

REDISTRIBUTION High-Speed Modems DAC

SAR + ADC CONTROL LOGIC

AGND AGND

GENERAL DESCRIPTION

The AD7888 is a high speed, low power, 12-bit ADC that oper- SPORT

ates from a single 2.7 V to 5.25 V power supply. The AD7888 is capable of a 125 k SPS throughput rate. The input track-and-

CS SCLKDOUTDIN

hold acquires a signal in 500 ns and features a single-ended sampling scheme. The AD7888 contains eight single-ended analog inputs, AIN1 through AIN8. The analog input on each

PRODUCT HIGHLIGHTS

of these channels is from 0 to VREF. The part is capable of con- www.BDTIC.com/ DI

1. Smallest 12-bit 8-channel ADC; 16-lead TSSOP is the same

verting full power signals up to 2.5 MHz. area as an 8-lead SOIC and less than half the height. The AD7888 features an on-chip 2.5 V reference that can be 2. Lowest Power 12-bit 8-channel ADC. used as the reference source for the A/D converter. The REF

3. Flexible power management options including automatic

IN/REF OUT pin allows the user access to this reference. Alter-

power-down after conversion.

natively, this pin can be overdriven to provide an external refer-

ence voltage for the AD7888. The voltage range for this external 4. Analog input range from 0 V to VREF (VDD).

reference is from 1.2 V to VDD.

5. Versatile serial I/O port (SPI/QSPI/MICROWIRE/DSP CMOS construction ensures low power dissipation of typically Compatible).

2 m W for normal operation and 3 µW in power-down mode. The part is available in a 16-lead narrow body small outline (SOIC) and a 16-lead thin shrink small outline (TSSOP) package.

SPI and QSPI are trademarks of Motorola, Inc. MICROWIRE is a trademark of National Semiconductor Corporation.

REV. Information furnished by Analog Devices is believed to be accurate and reliable. However, no responsibility is assumed by Analog Devices for its

use, nor for any infringements of patents or other rights of third parties that One Technology Way, P.O. Box 9106, Norwood, MA 02062-9106, U.S.A. may result from its use. No license is granted by implication or otherwise Tel: 781/329-4700 www.analog.com

under any patent or patent rights of Analog Devices. Fax: 781/326-8703 © Analog Devices, Inc., 2001

Page Summary Contents For AD7888 Analog Devices Data Sheet Manual

Page 1 2.7 V to 5.25 V, Micropower, 8-Channel, 125 k SPS, 12-Bit ADC in 16-Lead TSSOP AD7888 FEATURES FUNCTIONAL BLOCK DIAGRAM Specified for VDD of 2.7 V to 5.25 Flexible Power/Throughput Rate Management AD7...
Page 2 AD7888–SPECIFICATIONS (VDD = 2.7 V to 5.25 V, REFIN/REFOUT = 2.5 V External/Internal Reference unless otherwise noted; f SCLK = 2 MHz (VDD = 2.7 V to 5.25 V); TA = TMIN to TMAX, unless otherwise noted...
Page 3 AD7888 Parameter A Version1 B Version1 Unit Test Condition/Comment POWER REQUIREMENTS VDD 2.7/5.25 2.7/5.25 V min/max IDD Normal Mode5 (Static) µA max Normal Mode (Operational) µA typ f SAMPLE = 125 k...
Page 4 AD7888 TIMING SPECIFICATIONS1 (TA = TMIN to TMAX, unless otherwise noted) Limit at TMIN, TMAX (A, B Versions) Parameter 4.75 V to 5.25 V 2.7 V to 3.6 V Unit Description f SCLK MHz max t CONVERT 14.5 t...
Page 5 AD7888 PIN CONFIGURATIONS SOIC AND TSSOP CS SCLK REF IN/REF OUT DOUT VDD DIN AD7888 AGND TOP VIEW AIN1 AIN8 (Not to Scale) AIN2 AIN7 AIN3 AIN6 AIN4 AIN5 PIN FUNCTION DESCRIPTIONS Pin No. Mnemonic Func...
Page 6 AD7888 TERMINOLOGY Peak Harmonic or Spurious Noise Integral Nonlinearity Peak harmonic or spurious noise is defined as the ratio of the This is the maximum deviation from a straight line passing rms v...
Page 7 AD7888 CONTROL REGISTER The Control Register on the AD7888 is an 8-bit, write-only register. Data is loaded from the DIN pin of the AD7888 on the rising edge of SCLK. The data is transferred on the DI...
Page 8 AD7888 Figure 4 shows the typical power supply rejection ratio vs. CHARGE REDISTRIBUTION frequency for the part. The power supply rejection ratio is defined as the ratio of the power in the ADC output...
Page 9 AD7888 TYPICAL CONNECTION DIAGRAM For ac applications, removing high frequency components from Figure 8 shows a typical connection diagram for the AD7888. the analog input signal is recommended by use...
Page 10 AD7888 order to obtain optimum performance from the device it is the only way to fully power it up again is to reprogram the advised to disable the internal reference by setting the REF bit power mana...
Page 11 AD7888 THE PART REMAINS POWERED UP AT ALL TIMES AS PM1 AND PM0 = 0 DOUT 4 LEADING ZEROES + CONVERSION RESULT DATA INDIN CONTROL REGISTER DATA IS LOADED ON THE FIRST 8 CLOCKS. PM1 AND PM0 = 0 TO KEEP T...
Page 12 AD7888 THE PART ENTERS THE PART ENTERS SHUTDOWN AT THE END SHUTDOWN AT THE END OF OF CONVERSION AS THE PART BEGINS TO POWER- THE PART REMAINS POWERED CONVERSION AS PM1 = 1 PM1 = 1 AND PM0 = 0 UP FROM ...
Page 13 AD7888 SERIAL INTERFACE Writing of information to the Control Register takes place on Figure 16 shows the detailed timing diagram for serial interfac- the first eight rising edges of SCLK in a data tr...
Page 14 AD7888 MICROPROCESSOR INTERFACING The Timer Registers, etc., are loaded with a value that will The serial interface on the AD7888 allows the part to be directly provide an interrupt at the required sa...
Page 15 AD7888 AD7888 to MC68HC11 APPLICATION HINTS The Serial Peripheral Interface (SPI) on the MC68HC11 is Grounding and Layout configured for Master Mode (MSTR = 1), Clock Polarity Bit The AD7888 has very ...
Page 16 AD7888 OUTLINE DIMENSIONS Dimensions shown in inches and (mm). 16-Lead Small Outline (SOIC) PIN 1 0.0688 (1.75) 0.0196 (0.50) SEATING 0.0099 (0.25) 0.0500 (1.27) PLANE BSC 0.0075 (0.19) 0.0160 (0.41) ...
